Advance HCG/HCAG/HCVG Series Marine Gearbox
The input speed range of the Advance HCG/HCAG/HCVG Series marine gearbox is 1500-3200 RPM, with engine input power covering 20–3900 kW matching high-speed diesel engines at 1500-3200 RPM. The reduction ratio range is 1.00–3.50 and transfer capacity range covers full power grade for light high-speed vessels.
Advance HCG/HCAG/HCVG Series marine gearbox is composed of input coupling, multi-mode control system, output coupling, integrated oil cooler, fine oil filter, oil pressure gauge and other core standard components. The series supports mechanical cable, pneumatic and electric remote control systems with local manual emergency handle as standard. To meet different matching demands of various diesel engine brands and models, Advance HCG/HCAG/HCVG Series marine gearbox are supplied with multiple SAE flywheel housing sizes and optional gearbox covers.
All Advance marine gearboxes are certified by CCS as standard, and we are able to provide BV, LR, ABS, DNV&GL, RS and other major classification society certifications based on customer requirements with extra cost.
As official marine power pack supplier of Advance, SeaMac provides complete propulsion system and integrated power solution for all kinds of high-speed vessels worldwide. Mainly including marine high-speed engine, HCG/HCAG/HCVG gearbox, shaft system, propeller, marine genset, electric control lever system and full set of marine matching accessories. We also deliver full life cycle one-stop services for all global clients: from vessel power design & layout, complete power system supply, on-board installation & commissioning, operator after-sales training, global spare parts stock supply, on-site troubleshooting to professional overhaul technical support.
Advantages Of Advance HCG/HCAG/HCVG Series Marine Gearbox
1.Three layout options: vertical HCG, fixed 8° HCAG, adjustable 5°–14° HCVG. Flexible cabin layout and reliable matching with high-speed engines.
2.Lightweight aluminum housing, compact structure, easy operation and maintenance.
3.Precision ground helical gears; optimized oil circuit lowers noise and vibration at high speed.
4.Manufactured to European marine standards, sturdy, corrosion-resistant and stable in continuous operation.
5.Excellent reduction performance with integrated thrust bearing, removing the need for separate thrust block.
6.Professional technical support & global after-sales network, spare parts readily available.
Model | Input Speed Range | Power Range | Model | Input Speed Range | Power Range | ||
| HCG1068 | 1500-4000 RPM | 64.95-284.8 kw | HCG1220 | 1500-4500 RPM | 76.95-271.35 kw | ||
| HCG1280-1 | 1500-3600 RPM | 100.01-410.33 kw | HCG1305-3 | 1500-3000 RPM | 151.8-388.8 kw | ||
| HCG1400 | 1500-3000 RPM | 270.3-958.8 kw | HCG1500 | 1500-3000 RPM | 204.97-714.69 kw | ||
| HCG1665 | 1500-3000 RPM | 403.8-1342.8 kw | HCG2050 | 1500-2600 RPM | 466.65-808.86 kw | ||
| HCG3050 | 1000-2600 RPM | 46.64-121.264 kw | HCG5050 | 1500-2300 RPM | 947.85-1453.37 kw | ||
| HCG6400 | 1600-2100 RPM | 1649.6-1869 kw | HCG7650 | 1000-2100 RPM | 944-2946.51 kw | ||
| HCG9060 | 1000-2100 RPM | 1356-2847.6 kw | HCAG1090 | 1500-4500 RPM | 104.4-501.3 kw | ||
| HCAG3050 | 1000-2600 RPM | 466.4-1212.64 kw | HCAG5050 | 1500-2500 RPM | 947.85-1579.75 kw | ||
| HCAG6400 | 1600-2100 RPM | 1648-2163 kw | HCAG7650 | 1000-2100 RPM | 1319-2946.3 kw | ||
| HCAG9055 | 1000-2100 RPM | 1356-2847.6 kw | HCVG3710 | 1000-2500 RPM | 515-1287.5 kw | ||
| ——END—— | |||||||
Advance HCG/HCAG /HCVG Series Marine Gearbox
This is a list of all of Advance HCG/HCAG /HCVG series marine gearbox
Click here to find Advance marine gearbox by type (Reduction ratio & transfer capacity).
Advance HCG1068 Marine Gearbox
Input Speed Range: 1500-4000 r/min
Reduction Ratio: 1.26-2.78
Trans.Capacity: 0.0433-0.0442 kW/rpm
Power Range: 64.95-284.8 kw
Advance HCG1220 Marine Gearbox
Input Speed Range: 1500-4500 r/min
Reduction Ratio: 1.00-3.00
Trans.Capacity: 0.0603-0.0513 kW/rpm
Power Range: 76.95-271.35 kw
Advance HCG1280-1 Marine Gearbox
Input Speed Range: 1500-3600 r/min
Reduction Ratio: 1.00-3.00
Trans.Capacity: 0.0775-0.0667 kW/rpm
Power Range: 100.01-410.33 kw
Advance HCG1305-3 Marine Gearbox
Input Speed Range: 1500-3000 r/min
Reduction Ratio: 1.22-2.92
Trans.Capacity: 0.1296-0.1012 kW/rpm
Power Range: 151.8-388.8 kw
Advance HCG1400 Marine Gearbox
Input Speed Range: 1500-3000 r/min
Reduction Ratio: 0.85-2.96
Trans.Capacity: 0.1802 kW/rpm
Power Range: 270.3-958.8 kw
Advance HCG1500 Marine Gearbox
Input Speed Range: 1500-3000 r/min
Reduction Ratio: 1.13-1.97
Trans.Capacity: 0.2692 kW/rpm
Power Range: 204.97-714.69 kw
Advance HCG1665 Marine Gearbox
Input Speed Range: 1500-3000 r/min
Reduction Ratio: 1.11-2.59
Trans.Capacity: 0.29-0.2692 kW/rpm
Power Range: 403.8-1342.8 kw
Advance HCG2050 Marine Gearbox
Input Speed Range: 1500-2600 r/min
Reduction Ratio: 1.50-2.52
Trans.Capacity: 0.3111 kW/rpm
Power Range: 466.65-808.86 kw
Advance HCG3050 Marine Gearbox
Input Speed Range: 1000-2600 r/min
Reduction Ratio: 1.50-2.50
Trans.Capacity: 0.4664 kW/rpm
Power Range: 46.64-121.264 kw
Advance HCG5050 Marine Gearbox
Input Speed Range: 1500-2300 r/min
Reduction Ratio: 1.53-2.96
Trans.Capacity: 0.6319 kW/rpm
Power Range: 947.85-1453.37 kw
Advance HCG6400 Marine Gearbox
Input Speed Range: 1600-2100 r/min
Reduction Ratio: 1.48-3.07
Trans.Capacity: 1.031-0.89 kW/rpm
Power Range: 1649.6-1869 kw
Advance HCG7650 Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.55-3.17
Trans.Capacity: 1.204-0.94 kW/rpm
Power Range: 944-2946.51 kw
Advance HCG9060 Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.58-2.96
Trans.Capacity: 1.356 kW/rpm
Power Range: 1356-2847.6 kw
Advance HCAG1090 Marine Gearbox
Input Speed Range: 1500-4500 r/min
Reduction Ratio: 1.57-2.90
Trans.Capacity: 0.0696-0.06 kW/rpm
Power Range: 104.4-501.3 kw
Advance HCAG3050 Marine Gearbox
Input Speed Range: 1000-2600 r/min
Reduction Ratio: 1.35-3.00
Trans.Capacity: 0.4664-0.46 kW/rpm
Power Range: 466.4-1212.64 kw
Advance HCAG5050 Marine Gearbox
Input Speed Range: 1500-2500 r/min
Reduction Ratio: 2.03-2.96
Trans.Capacity: 0.6319 kW/rpm
Power Range: 947.85-1579.75 kw
Advance HCAG6400 Marine Gearbox
Input Speed Range: 1600-2100 r/min
Reduction Ratio: 2.93-3.00
Trans.Capacity: 1.03 kW/rpm
Power Range: 1648-2163 kw
Advance HCAG7650 Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.76-2.96
Trans.Capacity: 1.204-1.139 kW/rpm
Power Range: 1319-2946.3 kw
Advance HCAG9055 Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.97-2.95
Trans.Capacity: 1.356 kW/rpm
Power Range: 1356-2847.6 kw
Advance HCVG3710 Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 1.36-1.483
Trans.Capacity: 0.515 kW/rpm
Power Range: 515-1287.5 kw
