Advance GW/HC Series Marine Gearbox
The Advance GW/HC Series marine gearboxes cover a comprehensive power range, suitable for matching various marine diesel engines for ship propulsion. Each model features multiple optional reduction ratios to satisfy diverse vessel speed and thrust demands.
The gearbox consists of input coupling, output coupling, control system, oil cooler, oil filter, oil pressure gauge, oil pump and other core components. Both mechanical control and electric control versions are available for selection. To accommodate different brands and models of marine engines, the GW/HC Series supports multiple SAE flywheel and housing specifications for flexible installation adaptation.
All Advance GW/HC marine gearboxes can be supplied with CCS classification certificates. Certifications from international classification societies including BV, LR, ABS, DNV-GL, RS, KR, RINA and NK are available at additional cost.
As an official Advance power pack integrator, SeaMac delivers complete propulsion and power system solutions for vessels worldwide. The supply scope covers marine engines, gearboxes, shafting, propellers, marine generator sets, electric control lever systems and a full range of marine auxiliary parts. We provide full-lifecycle services including project design, power system supply, on-site installation & commissioning, after-sales training, genuine spare parts supply, troubleshooting and professional overhaul technical support.
Advantages Of Advance GW/HC Series Marine Gearbox
- Innovative structural design delivers outstanding operational reliability. Optimized layout enables softer, smoother installation matching between gearbox and engine.
- Compact dimension and lightweight construction. High usability and convenient maintenance are fully prioritized during design.
- Superior mechanical performance. Well-engineered structure effectively lowers running noise and suppresses vibration.
- Manufactured to European standard specifications, featuring robust structure, long service life and stable smooth operation.
- Reliable speed reduction capability, capable of bearing propeller axial thrust.
- Supported by professional gearbox technical specialists, readily available after-sales service and stocked genuine spare parts.
Model | Input Speed Range | Power Range | Model | Input Speed Range | Power Range | ||
| GWC28.30P | 1000-2500 RPM | 290-2162.5 kw | GWC30.32P | 1000-2500 RPM | 376-2805 kw | ||
| GWC32.35P | 1000-2500 RPM | 480-3542.5 kw | GWC36.39P | 1000-2500 RPM | 634-4800 kw | ||
| GWC39.41P | 1000-2500 RPM | 852-6462.5 kw | GWC42.45P | 1000-2100 RPM | 1106-6888 kw | ||
| GWC45.49P | 1000-2100 RPM | 1398-8904 kw | GWC49.54P | 1000-2100 RPM | 1861-11550 kw | ||
| GWC52.59P | 1000-2100 RPM | 2426-15619.8 kw | GWC60.66P | 1000-2100 RPM | 3000-20817.3 kw | ||
| GWC63.71P | 1000-2100 RPM | 3294-25683 kw | GWS28.30P | 1000-2500 RPM | 220-228.15 kw | ||
| GWS30.32P | 1000-2500 RPM | 142.5-723.35 kw | GWS32.35P | 1000-2500 RPM | 720-1800 kw | ||
| GWS36.39P | 1000-2500 RPM | 960-2400 kw | GWS39.41P | 1000-2500 RPM | 1260-3150 kw | ||
| GWS42.45P | 1000-2100 RPM | 1640-3444 kw | GWS45.49P | 1000-2100 RPM | 2120-4452 kw | ||
| GWS49.54P | 1000-2100 RPM | 2825-5932.5 kw | GWS52.59P | 1000-2100 RPM | 3640-7644 kw | ||
| GWS60.66P | 1000-2100 RPM | 5050-10605 kw | HC400P | 1000-3000 RPM | 170-993 kw | ||
| HC600P | 1000-3000 RPM | 360-1470 kw | HC1200P | 1000-2500 RPM | 650-2325 kw | ||
| HC1200/1P | 1000-2500 RPM | 650-2325 kw | HC1600P | 1000-2500 RPM | 1000-3150 kw | ||
| HC2000P | 1000-2100 RPM | 1330-3318 kw | HC2700P | 1000-2100 RPM | 1625-4410 kw | ||
| HCD400P | 1000-3000 RPM | 235-993 kw | HCD600P | 1000-3000 RPM | 324-1470 kw | ||
| HCD800P | 1000-2500 RPM | 490-1562.5 kw | HCD1400P | 1000-2500 RPM | 800-2702.5 kw | ||
| HCD1600P | 1000-2500 RPM | 860-3150 kw | HCD2000P | 1000-2100 RPM | 1200-3318 kw | ||
| HCD2700P | 1000-2100 RPM | 1625-4410 kw | HCT400P | 1000-3000 RPM | 243-993 kw | ||
| HCT600P | 1000-3000 RPM | 291-1350 kw | HCT800P | 1000-2500 RPM | 480-1562.5 kw | ||
| HCT1200P | 1000-2500 RPM | 700-2325 kw | HCT1400P | 1000-2500 RPM | 850-2702.5 kw | ||
| HCT1600P | 1000-2500 RPM | 811-3150 kw | HCT2000P | 1000-2100 RPM | 1300-3318 kw | ||
| HCT2700P | 1000-2100 RPM | 1500-4410 kw | |||||
| ——END—— | |||||||
Advance GW/HC Series Marine Gearbox
This is a list of all of Advance GW/HC series marine gearbox
Click here to find Advance marine gearbox by type (Reduction ratio & transfer capacity).
Advance GWC28.30P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 2.03-6.05
Trans.Capacity: 0.865-0.29 kW/rpm
Power Range: 290-2162.5 kw
Advance GWC30.32P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 2.03-6.05
Trans.Capacity: 1.122-0.375 kW/rpm
Power Range: 376-2805 kw
Advance GWC32.35P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 2.06-6.08
Trans.Capacity: 1.417-0.48 kW/rpm
Power Range: 480-3542.5 kw
Advance GWC36.39P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 1.97-5.97
Trans.Capacity: 1.92-0.0634 kW/rpm
Power Range: 634-4800 kw
Advance GWC39.41P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 1.98-5.99
Trans.Capacity: 2.585-0.852 kW/rpm
Power Range: 852-6462.5 kw
Advance GWC42.45P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 2.00-5.93
Trans.Capacity: 3.28-1.106 kW/rpm
Power Range: 1106-6888 kw
Advance GWC45.49P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.97-5.98
Trans.Capacity: 4.24-1.398 kW/rpm
Power Range: 1398-8904 kw
Advance GWC49.54P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.94-6.00
Trans.Capacity: 5.5-1.861 kW/rpm
Power Range: 1861-11550 kw
Advance GWC52.59P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.93-5.93
Trans.Capacity: 7.438-2.426 kW/rpm
Power Range: 2426-15619.8 kw
Advance GWC60.66P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 2.01-6.97
Trans.Capacity: 9.913-3.00 kW/rpm
Power Range: 3000-20817.3 kw
Advance GWC63.71P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 2.01-7.48
Trans.Capacity: 12.23-3.294 kW/rpm
Power Range: 3294-25683 kw
Advance GWS28.30P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 2.0-4.05
Trans.Capacity: 0.44 kW/rpm
Power Range: 220-228.15 kw
Advance GWS30.32P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 1.97-4.00
Trans.Capacity: 0.57 kW/rpm
Power Range: 142.5-723.35 kw
Advance GWS32.35P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 2.00-4.05
Trans.Capacity: 0.72 kW/rpm
Power Range: 720-1800 kw
Advance GWS36.39P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 2.03-3.95
Trans.Capacity: 0.96 kW/rpm
Power Range: 960-2400 kw
Advance GWS39.41P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 2.00-3.95
Trans.Capacity: 1.26 kW/rpm
Power Range: 1260-3150 kw
Advance GWS42.45P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.97-4.00
Trans.Capacity: 1.64 kW/rpm
Power Range: 1640-3444 kw
Advance GWS45.49P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 2.03-3.95
Trans.Capacity: 2.12 kW/rpm
Power Range: 2120-4452 kw
Advance GWS49.54P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.97-3.95
Trans.Capacity: 2.825 kW/rpm
Power Range: 2825-5932.5 kw
Advance GWS52.59P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 1.97-3.95
Trans.Capacity: 3.64 kW/rpm
Power Range: 3640-7644 kw
Advance GWS60.66P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 2.00-3.95
Trans.Capacity: 5.05 kW/rpm
Power Range: 5050-10605 kw
Advance HC400P Marine Gearbox
Input Speed Range: 1000-3000 r/min
Reduction Ratio: 1.50-4.94
Trans.Capacity: 0.331-0.17 kW/rpm
Power Range: 170-993 kw
Advance HC600P Marine Gearbox
Input Speed Range: 1000-3000 r/min
Reduction Ratio: 2.00-3.89
Trans.Capacity: 0.49-0.36 kW/rpm
Power Range: 360-1470 kw
Advance HC1200P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 1.60-4.47
Trans.Capacity: 0.93-0.65 kW/rpm
Power Range: 650-2325 kw
Advance HC1200/1P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 3.70-5.58
Trans.Capacity: 0.93-0.62 kW/rpm
Power Range: 650-2325 kw
Advance HC1600P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 2.03-4.00
Trans.Capacity: 1.26-1.00 kW/rpm
Power Range: 1000-3150 kw
Advance HC2000P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 2.28-4.40
Trans.Capacity: 1.58-1.33 kW/rpm
Power Range: 1330-3318 kw
Advance HC2700P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 2.03-4.47
Trans.Capacity: 2.1-1.625 kW/rpm
Power Range: 1625-4410 kw
Advance HCD400P Marine Gearbox
Input Speed Range: 1000-3000 r/min
Reduction Ratio: 3.96-5.89
Trans.Capacity: 0.331-0.235 kW/rpm
Power Range: 235-993 kw
Advance HCD600P Marine Gearbox
Input Speed Range: 1000-3000 r/min
Reduction Ratio: 4.18-5.71
Trans.Capacity: 0.49-0.324 kW/rpm
Power Range: 324-1470 kw
Advance HCD800P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 3.43-5.89
Trans.Capacity: 0.625-0.49 kW/rpm
Power Range: 490-1562.5 kw
Advance HCD1400P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 4.04-5.86
Trans.Capacity: 1.081-0.80 kW/rpm
Power Range: 800-2702.5 kw
Advance HCD1600P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 2.97-5.94
Trans.Capacity: 1.26-0.86 kW/rpm
Power Range: 860-3150 kw
Advance HCD2000P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 3.00-6.05
Trans.Capacity: 1.58-1.20 kW/rpm
Power Range: 1200-3318 kw
Advance HCD2700P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 3.65-6.11
Trans.Capacity: 2.1-1.625 kW/rpm
Power Range: 1625-4410 kw
Advance HCT400P Marine Gearbox
Input Speed Range: 1000-3000 r/min
Reduction Ratio: 6.09-9.47
Trans.Capacity: 0.331-0.243 kW/rpm
Power Range: 243-993 kw
Advance HCT600P Marine Gearbox
Input Speed Range: 1000-3000 r/min
Reduction Ratio: 6.06-9.35
Trans.Capacity: 0.45-0.291 kW/rpm
Power Range: 291-1350 kw
Advance HCT800P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 4.95-8.40
Trans.Capacity: 0.625-0.480 kW/rpm
Power Range: 480-1562.5 kw
Advance HCT1200P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 5.05-7.92
Trans.Capacity: 0.93-0.70 kW/rpm
Power Range: 700-2325 kw
Advance HCT1400P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 4.06-9.55
Trans.Capacity: 1.081-0.85 kW/rpm
Power Range: 850-2702.5 kw
Advance HCT1600P Marine Gearbox
Input Speed Range: 1000-2500 r/min
Reduction Ratio: 5.55-12.52
Trans.Capacity: 1.26-0.811 kW/rpm
Power Range: 811-3150 kw
Advance HCT2000P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 5.19-11.0
Trans.Capacity: 1.58-1.3 kW/rpm
Power Range: 1300-3318 kw
Advance HCT2700P Marine Gearbox
Input Speed Range: 1000-2100 r/min
Reduction Ratio: 4.92-11.54
Trans.Capacity: 2.10-1.50 kW/rpm
Power Range: 1500-4410 kw
