Advance HCM403 Marine Gearbox

The speed input range of the Advance HCM403 marine gearbox is 1000–2300 RPM, with engine input power from 315 kW to 724.5 kW. The center distance is 260 mm, the reduction ratio range is 1.00–2.55, the transmission capacity range is 0.315–0.332 kW/RPM, and the input shaft rotates opposite to the output shaft.
Advance HCM403 marine gearbox consists of transmission shaft, output coupling, input coupling, oil pressure gauge, oil filter, control system, oil pump and other core components.
Advance HCM403 marine gearbox is fitted with an electric control system. To satisfy matching requirements for various engine brands and models, the Advance HCM403 marine gearbox supports multiple engine flywheel sizes for flexible installation.
All Advance HCM403 series marine gearboxes are available with CCS classification certificates. Additional fees apply for certifications from international classification societies, mainly including French BV, British LR, American ABS, Japanese NK, Norway DNV-GL, Russia RS, South Korea KR, Italy RINA and other mainstream classification societies.

Advantages Of Advance HCM403 Marine Gearbox

The HCM403 marine gearbox adopts an innovative structural design, delivering outstanding long-term operational reliability. Its optimized layout enables softer, smoother alignment between the gearbox and supporting diesel engine.
Compact overall dimensions with reasonable weight distribution bring superior handling performance. The full design cycle prioritizes convenient daily operation and straightforward routine maintenance for users.
Boasting premium mechanical performance, the refined structural design effectively suppresses operating noise and dampens mechanical vibration during navigation.
Compatible with a full range of domestic and imported medium & high-speed marine diesel engines, the unit supports horizontal installation layouts to satisfy diverse vessel layout requirements. It features stable, efficient deceleration performance and robust structural capacity to withstand large propeller thrust loads.
Backed by professional marine gearbox technical engineers and comprehensive global after-sales support, all common replacement spare parts are kept in stock for fast delivery.

Technical Specifications

Gearbox Model:	HCM403
Input Speed:	1000-2300 RPM
Power:	315-724.5 kW
Center Distance:	200 mm
Trans.Capacity:	0.315 kW / RPM
Reduction Ratio:	1.00
Rated Thrust:	Unable to bear
Net Weight:	390 kg
Lead Time:	15-30 Working Days
Payment Terms:	T/T ,L/C

Coming soon

Model	Input Speed	Reduction Ratio	Trans. Capacity	Center Distance	Net Weight
HCM165	1500-3600 RPM	1.18-1.24	0.087 kW/rpm	146 mm	130.5 kg
HCM303	1000-2100 RPM	1.00-1.19	0.262 kW/rpm	190 mm	290 kg
HCM403	1000-2300 RPM	1.00	0.315 kW/rpm	200 mm	390 kg
——END——

Technical Specifications of Advance HCM403 Marine Gearbox
Model	HCM403	Power(kW)	315-724.5	Center Distance(mm)	200
Input Speed(r/min)	1000-2300	Reduction Ratio(i)	1.00	Trans. Capacity(kW/rpm)	0.315
Rated Thrust(kN)	Unable to bear	Net Weight(kg)	390
——END——

1. The Marine gearbox has the function of reverse, clutch, deceleration and the thrust of the propeller, which is equipped with the main engine to form the Marine power unit.
2. The “transfer capacity” refers to the ratio of the engine’s rated power to the rated speed, and the reduction ratio corresponds to the transmission capacity, which should be less than the number be offered.
3. The gearbox and engine shafting are not allowed to use rigid connection, and the bracket is recommended to be installed on the same rigid support.If the engine is mounted on the elastic support, and the gearbox is installed on the rigid support, please contact the technical department of the company to select the suitable high elastic coupling.
4. The weight of the gearbox is approximation, for different reduction ratio the weight is different.
5. Due to the technical improvement of the products, the products may change without notice. For any other questions please contact our sales engineer.

ANGLE OF TILT
Name	Transverse Direction		Longitudinal Direction
	Heeling	Rolling	Heeling	Rolling
Marine Gearbox	15°	22.5°	5°	7.5°
——END——

coming soon

Marine Gearboxs Conventional Wearing Parts
External disc	Internal disc	Sealing	Piston ring
Gasket	Rubber sealing	Thrust plate	Filter
Coil type filter	Packing	O ring	Input shaft assembly
Transmission shaft assemby	Output shaft assembly	Hydraulic control system
