Advance GWS70.111 Marine Gearbox

The speed input range of the Advance GWS70.111 marine gearbox is 400–900 RPM, with engine input power from 3244 kW to 7299 kW. The reduction ratio range is 4.58–5.95, the transmission capacity is 8.11 kW/RPM, the rated propeller thrust is 1200 KN, and the input shaft is opposite to the output shaft.
Advance GWS70.111 marine gearbox consists of transmission shaft, output coupling, input coupling, oil pressure gauge, oil filter, control system, oil pump and other key components.
Advance GWS70.111 marine gearbox offers two types of control systems for customer selection: electric control and pneumatic control. To satisfy diverse matching requirements for various engine brands and models, Advance GWS70.111 marine gearbox supports multiple engine flywheel sizes.
All Advance GWS series marine gearboxes can be supplied with CCS classification certificates. Selected series are available with international classification society certifications at additional cost, mainly including French BV, British LR, American ABS, Japanese NK, Norwegian DNV-GL, Russian RS, Korean KR, Italian RINA and other classification societies.

Advantages Of Advance GWS70.111 Marine Gearbox

Gearbox features novel structure to guarantee reliable operation. Superior design enables more flexible and smooth layout arrangement between the gearbox and engine.
Compact structure, small overall dimension, light weight and favorable maneuverability. The design fully takes convenience of operation and maintenance into consideration.
The gearbox adopts modular combined design. All rotating components are elaborately designed and machined in strict accordance with high standards to reduce fuel consumption and ensure stable operation, which can match most engine models.
1-stage reduction design with parallel input & output shafts and opposite rotation direction. It is equipped with reverse clutch reduction function.
We have professional gearbox engineering team and complete after-sales service, with spare parts available from stock.

Technical Specifications

Gearbox Model:	GWS70.111
Input Speed:	400-900 r / min
Power:	3244-7299 kw
Center Distance:	N/A
Trans.Capacity:	8.11 kw/r/min
Reduction Ratio:	4.58-5.95
Rated Thrust:	1200 kN
Dimension:	N/A
Net Weight:	N/A
Lead Time:	15-30 Working Days
Payment Terms:	T/T ,L/C

Coming soon

Model	Input Speed	Reduction Ratio	Trans. Capacity	Rated Thrust	Net Weight
GWS28.30	400-1800 r/min	2.00-4.05	0.44 kw/r/min	80 kN	1230 kg
GWS30.32A	400-1800 r/min	1.97-4.00	0.57-0.52 kw/r/min	100 kN	1460 kg
GWS32.35	400-1800 r/min	2.00-4.05	0.72 kw/r/min	120 kN	2250 kg
GWS36.39	400-1800 r/min	2.03-3.95	1.02 kw/r/min	140 kN	2450 kg
GWS36.54	400-1800 r/min	4.46-5.95	0.96 kw/r/min	220 kN	N/A
GWS39.41	400-1600 r/min	2.00-3.95	1.40 kw/r/min	175 kN	3230 kg
GWS39.57	400-1600 r/min	4.52-5.95	1.29 kw/r/min	270 kN	N/A
GWS42.45	400-1600 r/min	1.97-4.00	1.81 kw/r/min	220 kN	3960 kg
GWS42.45 Q	400-1600 r/min	1.97-4.00	1.573 kw/r/min	220 kN	3600 kg
GWS42.63	400-1600 r/min	4.46-5.95	1.64 kw/r/min	290 kN	N/A
GWS45.49	400-1400 r/min	2.03-3.95	2.23 kw/r/min	270 kN	6030 kg
GWS45.68	400-1400 r/min	4.50-5.95	2.12 kw/r/min	360 kN	N/A
GWS49.54	400-1200 r/min	1.97-3.95	3.26 kw/r/min	290 kN	7900 kg
GWS49.61	400-1200 r/min	4.45-5.5	2.825-2.47 kw/r/min	290 kN	8500 kg
GWS49.74	400-1200 r/min	4.58-5.95	2.83 kw/r/min	540 kN	N/A
GWS52.59	400-1200 r/min	1.97-3.95	3.8067 kw/r/min	300 kN ( with sliding bearing is 360 kN)	8900 kg
GWS52.71	400-1200 r/min	4.58-5.95	3.8067 kw/r/min	540 kN	1230 kg
GWS52.82	400-1200 r/min	4.58-5.95	3.64 kw/r/min	710 kN	N/A
GWS60.66	400-1200 r/min	2.00-3.95	5.09 kw/r/min	450 kN ( with sliding bearing is 540 kN)	15000 kg
GWS60.75	400-1200 r/min	5.00-6.00	5.09-4.25 kw/r/min	700 kN	18300 kg
GWS60.92	400-1200 r/min	4.52-5.95	5.05 kw/r/min	750 kN	N/A
GWS63.71	300-1000 r/min	2.00-4.11	6.45 kw/r/min	710 kN	17000 kg
GWS63.95	400-1000 r/min	4.50-5.95	6.0 kw/r/min	800 kN	N/A
GWS66.75	350-950 r/min	1.97-3.95	7.48 kw/r/min	730 kN	20000 kg
GWS66.106	400-950 r/min	4.52-6.05	7.20 kw/r/min	980 kN	N/A
GWS70.76	300-900 r/min	1.94-3.95	8.15 kw/r/min	750 kN	22500 kg
GWS70.82	300-900 r/min	1.94-4.25	9.15-8.40 kw/r/min	780 kN	N/A
GWS70.111	400-900 r/min	4.58-5.95	8.11 kw/r/min	1200 kN	N/A
——END——

Technical Specifications of Advance GWS70.111 Marine Gearbox
Model	GWS70.111	Power(kW)	3244-7299	Center Distance(mm)	N/A
Input Speed(r/min)	400-900	Reduction Ratio(i)	4.58 5.04 5.59 5.95	Trans. Capacity(kW/rpm)	8.11
Rated Thrust(kN)	1200	Net Weight(kg)	N/A	Controls	N/A
——END——

The Marine gearbox has the function of reverse, clutch, deceleration and the thrust of the propeller, which is equipped with the main engine to form the Marine power unit.
The “transfer capacity” refers to the ratio of the engine’s rated power to the rated speed, and the reduction ratio corresponds to the transmission capacity, which should be less than the number be offered.
The gearbox and engine shafting are not allowed to use rigid connection, and the bracket is recommended to be installed on the same rigid support.If the engine is mounted on the elastic support, and the gearbox is installed on the rigid support, please contact the technical department of the company to select the suitable high elastic coupling.
The weight of the gearbox is approximation, for different reduction ratio the weight is different.
Due to the technical improvement of the products, the products may change without notice. For any other questions please contact our sales engineer.

ANGLE OF TILT
Name	Transverse Direction		Longitudinal Direction
	Heeling	Rolling	Heeling	Rolling
Marine Gearbox	15°	22.5°	5°	7.5°
——END——

Optional Accessories of Advance GWS70.111 Marine Gearbox
Bell Housing	195C	Input Coupling	1. Highly Flexible Coupling
	/		2. Toothed Input Coupling
Direction of Input Shaft Rotation	1. Anti-clockwise (Facing the Output End)	VDO	Gearbox Pressure Visible on Bridge
	2. Clockwise (Facing the Output End)
Alarm Device	1. Temperature	Control System	1. Mechanical
	2. Working Pressure		2. Electrical
	3. Lubricating Oil Pressure		3. Pneumatical
Gauge	Oil Temperature

Modifiable Components of Advance GWS70.111 Marine Gearbox
Special Reduction Ratio	According to Customer’s Special Requirements	Replacement of Imported Bearing	1. Stronger Endurance
			2. Longer Service Life
			3. Higher Limit Speed
PTO	Power Take Off	Output Shaft Coupling	Based on Customers data to produce
——END——

Marine Gearboxs Conventional Wearing Parts
External disc	Internal disc	Sealing	Piston ring
Gasket	Rubber sealing	Thrust plate	Filter
Coil type filter	Packing	O ring	Input shaft assembly
Transmission shaft assemby	Output shaft assembly	Hydraulic control system
