Advance GWH49.74 Marine Gearbox

The speed input range of the Advance GWH49.74 marine gearbox is 400–1200 RPM, with engine input power from 1132 kW to 3396 kW. The reduction ratio range is 4.58–5.95, the transmission capacity is 2.83 kW/RPM, the rated propeller thrust is 540 KN, and the input shaft is opposite to the output shaft.
Advance GWH49.74 marine gearbox consists of transmission shaft, output coupling, input coupling, oil pressure gauge, oil filter, control system, oil pump and other key components.
Advance GWH49.74 marine gearbox offers two types of control systems for customer selection: electric control and pneumatic control. To satisfy diverse matching requirements for various engine brands and models, Advance GWH49.74 marine gearbox supports multiple engine flywheel sizes.
All Advance GWH series marine gearboxes can be supplied with CCS classification certificates. Selected series are available with international classification society certifications at additional cost, mainly including French BV, British LR, American ABS, Japanese NK, Norwegian DNV-GL, Russian RS, Korean KR, Italian RINA and other classification societies.

Advantages Of Advance GWH49.74 Marine Gearbox

Gearbox features novel structure to guarantee reliable operation. Superior design enables more flexible and smooth layout arrangement between the gearbox and engine.
Compact structure, small overall dimension, light weight and favorable maneuverability. The design fully takes convenience of operation and maintenance into consideration.
The gearbox adopts modular combined design. All rotating components are elaborately designed and machined in strict accordance with high standards to reduce fuel consumption and ensure stable operation, which can match most engine models.
1-stage reduction design with parallel input & output shafts and opposite rotation direction. It is equipped with reverse clutch reduction function.
We have professional gearbox engineering team and complete after-sales service, with spare parts available from stock

Technical Specifications

Gearbox Model:	GWH49.74
Input Speed:	400-1200 r / min
Power:	1132-3396 kw
Center Distance:	N/A
Trans.Capacity:	2.83 kw/r/min
Reduction Ratio:	4.58-5.95
Rated Thrust:	540 kN
Dimension:	N/A
Net Weight:	N/A
Lead Time:	15-30 Working Days
Payment Terms:	T/T ,L/C

Coming soon

Model	Input Speed	Reduction Ratio	Trans. Capacity	Rated Thrust	Net Weight
GWH28.30	400-1800 r/min	2.00-4.05	0.44 kw/r/min	80 KN	1230 kg
GWH30.32A	400-1800 r/min	1.97-4.00	0.570-0.520 kw/r/min	100 KN	1350 kg
GWH32.35	400-1800 r/min	2.00-4.05	0.72 kw/r/min	120 KN	2080 kg
GWH36.39	400-1800 r/min	2.03-3.95	1.02 kw/r/min	140 KN	2450 kg
GWH36.54	400-1800 r/min	4.46-5.95	0.96 kw/r/min	220 KN	N/A
GWH39.41	400-1600 r/min	2.00-3.95	1.400 kw/r/min	175 KN	2960 kg
GWH39.57	400-1600 r/min	4.52-5.95	1.290 kw/r/min	270 KN	N/A
GWH42.45	400-1600 r/min	1.97-4.00	1.810 kw/r/min	220 KN	3960 kg
GWH42.63	400-1600 r/min	4.46-5.95	1.640 kw/r/min	290 kN	N/A
GWH45.49	400-1400 r/min	2.03-3.95	2.23 kw/r/min	270 KN	5560 kg
GWH45.68B	400-1400 r/min	4.5-5.95	2.21 kw/r/min	360 kN	N/A
GWH49.54	400-1200 r/min	1.97-3.95	3.26 kw/r/min	290 KN	7300 kg
GWH49.74	400-1200 r/min	4.45-5.5	2.825-2.47 kw/r/min	290 kN	N/A
GWH52.59	400-1200 r/min	1.97-3.95	3.8067 kw/r/min	300 kN ( with sliding bearing is 360 kN)	8900 kg
GWH52.82	400-1200 r/min	4.58-5.95	3.8067 kw/r/min	710 kN	N/A
GWH60.66	400-1200 r/min	2.00-3.95	5.09 kw/r/min	450 kN ( with sliding bearing is 540 kN)	14000 kg
GWH60.92	400-1200 r/min	4.52-5.95	5.05 kw/r/min	750 kN	N/A
GWH63.71	300-1000 r/min	2.00-4.11	6.45 kw/r/min	710 kN	17000 kg
GWH63.95	400-1000 r/min	4.5-5.95	6.00 kw/r/min	800 kN	N/A
GWH66.75	300-950 r/min	1.97-3.95	7.48 kw/r/min	730 KN	19000 kg
GWH66.106	400-950 r/min	4.52-6.05	7.2 kw/r/min	980 kN	N/A
GWH70.76	300-900 r/min	1.94-3.95	8.15 kw/r/min	750 KN	21500 kg
GWH70.82	300-900 r/min	1.94-4.25	9.15-8.40 kw/r/min	780 kN	N/A
GWH70.111	400-900 r/min	4.58-5.95	8.11 kw/r/min	1200 kN	N/A
——END——

Technical Specifications of Advance GWH49.74 Marine Gearbox
Model	GWH49.74	Power(kW)	1132-3396	Center Distance(mm)	N/A
Input Speed(r/min)	400-1200	Reduction Ratio(i)	4.58 5.04 5.59 5.95	Trans. Capacity(kW/rpm)	2.83
Rated Thrust(kN)	540	Net Weight(kg)	N/A	Controls	N/A
——END——

The Marine gearbox has the function of reverse, clutch, deceleration and the thrust of the propeller, which is equipped with the main engine to form the Marine power unit.
The “transfer capacity” refers to the ratio of the engine’s rated power to the rated speed, and the reduction ratio corresponds to the transmission capacity, which should be less than the number be offered.
The gearbox and engine shafting are not allowed to use rigid connection, and the bracket is recommended to be installed on the same rigid support.If the engine is mounted on the elastic support, and the gearbox is installed on the rigid support, please contact the technical department of the company to select the suitable high elastic coupling.
The weight of the gearbox is approximation, for different reduction ratio the weight is different.
Due to the technical improvement of the products, the products may change without notice. For any other questions please contact our sales engineer.

ANGLE OF TILT
Name	Transverse Direction		Longitudinal Direction
	Heeling	Rolling	Heeling	Rolling
Marine Gearbox	15°	22.5°	5°	7.5°
——END——

Optional Accessories of Advance GWH49.74 Marine Gearbox
Bell Housing	195C	Input Coupling	1. Highly Flexible Coupling
	/		2. Toothed Input Coupling
Direction of Input Shaft Rotation	1. Anti-clockwise (Facing the Output End)	VDO	Gearbox Pressure Visible on Bridge
	2. Clockwise (Facing the Output End)
Alarm Device	1. Temperature	Control System	1. Mechanical
	2. Working Pressure		2. Electrical
	3. Lubricating Oil Pressure		3. Pneumatical
Gauge	Oil Temperature

Modifiable Components of Advance GWH49.74 Marine Gearbox
Special Reduction Ratio	According to Customer’s Special Requirements	Replacement of Imported Bearing	1. Stronger Endurance
			2. Longer Service Life
			3. Higher Limit Speed
PTO	Power Take Off	Output Shaft Coupling	Based on Customers data to produce
——END——

Marine Gearboxs Conventional Wearing Parts
External disc	Internal disc	Sealing	Piston ring
Gasket	Rubber sealing	Thrust plate	Filter
Coil type filter	Packing	O ring	Input shaft assembly
Transmission shaft assemby	Output shaft assembly	Hydraulic control system
——END——
